Seat Surface Load Pad GT-LB01-13

(Furniture Testing)

Contact Now

Description

BIFMA Bag Type Impactor device

Applications:

This Seat Surface Load Pad is suitable for testing seat, office chair forward stability test.

Standards:

ANSI/BIFMA X5.1 - 2017 Section 11.4, EN 1335-3-2009 Section 7.1.2, 7.1.3, EN 1022 -2018 Section 5.5

Key Specifications

Model	GT-LB01-13
Material	Aluminum & plastic
Pad diameter	200mm
Pad camber surface	R300mm
Arm length	240mm
Dimension (L×W×D)	440×200×37mm
Weight	2 kg
Standards	ANSI/BIFMA X5.1 - 2017 Section 11.4, EN 1335-3-2009 Section 7.1.2, 7.1.3

Applications Industry

All kinds of seats of chair can be tested on the Seat Surface Load Pad GT-LB01-13
