3 Stations Chair Seating and Back Testing Machine

BIFMA X5.4 Chair Seating and Back Testing Machine GT-LB04-3C

(Furniture Testing)

Item NO.:
GT-LB04-3C
Lead Time:
15-30 days
Brand:
GESTER
Payment:
TT or L/C
certificate:
ISO 9001, UKAS, CE

Contact Now

Description

Applications:

The chair tester tests the strength and durability of the seats and backrests by simulating the routine use loading of the seat.

The machine is equipped with 3 working position, which can test a three-seat chair or sofa at the same time.

Each working position equips with two drive units, and can be individually controlled to repeatedly load the test points of the seat. Through different parameter settings.

Feature:

1.The sofa chair strength and durability testing equipment adopts frame structure design. The frame is made of high quality industrial aluminum, beautiful and easy to maintain.

2. The driving device of this machine adopts a unique combination of servo proportional valve and cylinder, which is an innovative product developed by our company. Compared with the traditional cylinder, it has higher transmission precision, more stable load maintenance and faster testing speed. It can be adjusted freely in the vertical direction according to the sample, which is convenient for different products.

3. PLC controller to control the actions of the instrument; the operation is intuitive and simple.

4. The angle of the backrest loading device can be adjusted.

5.Chair Seating and Back Testing Machine is equipped with seat impact function.

Standards:

BIFMA X5.4-2020 Section 5,6,7,8,9,10,11,12,14,15,16,20,21.3,21.4,21.6,22,23,24,25,26

Key Specifications:

Model	GT-LB04-3C
Working position	3
Drive Device	Cylinder + servo proportional valve
Seat surface load capacity	2500N
backrest load capacity	2500N
Seat surface height	15 - 70cm
Testing time	0-99999 ( can be adjustment)
Seat impactor weight	Max.350Lbs (accumulated)
Control method	PLC touch screen control

Installation Details:

Compression air requirement	≥0.6Mpa
Power	1 phase AC 220V 50/60Hz
Dimension (W x D x H)	6000x2520x2600mm
Weight	1500kg

Accessories:

Standards accessories	3pcs	GT-LB01-2A Seat loading pad
	3pcs	GT-LB01-3 Smaller seat loading pad
	3pcs	GT-LB01-4 Back loading pad
	6pcs	GT-LB01-5 Local loading pad
	1set	BIFMA Impact bag (350Lbs)
	3pcs	406&200mm Loading pad
	2pcs	GT-LB01-8 203mm loading pad
	2pcs	GT-LB01-9 BIFMA102&50mm loading pad
	3pcs	Stationary fixture
	8pcs	Stops
