Station number and name
|
Test items
|
Accessories
|
|
1.(Seat & Backrest Strength, Endurance and Impact Test)
|
EN 1728-6.4: Seat and back static load test
|
1pc: Large seating loading pad
1pc: Back loading pad
1pc: Local loading pad
1set: EN seating impact head
1set: Bifma impact bag
1pc: GT-LB21 Stability test -Support apparatus
13pcs: GT-LB22 Loading Disk
1pc: GT-LB23 Support Fixture
1set: Seat holder
|
|
EN1728-6.7: Horizontal forward static load test on back rests
|
|
|
EN1728-6.9： Leg rest static load test
|
|
|
EN1728-6.12: Headrest static load test
|
|
|
EN1728-6.15: Leg forward static load test
|
|
|
EN1728-6.16: Leg sideways static load test
|
|
|
EN1728-6.17: Combined seat and back durability test
|
|
|
EN1728-6.24 ：Seat impact test
|
|
|
EN1728-7.3: Combined seat and back static load test
|
|
|
EN1728-7.9: Seat and back durability test
|
|
|
BIFMAX5.1 Section 7 Drop Test - Dynamic
|
|
|
BIFMAX5.1 Section 10.3Seating Impact Test
|
|
|
BIFMAX5.1 Section11.3.1 Rear Stability Test for Type III Chairs
|
|
|
BIFMAX5.1 Section11.3.2 Rear Stability Test for Type I and II Chairs
|
|
|
EN1022 section7
|
|
|
2.(Armrest strength, durability & Tilt mechanism durability test)
|
EN1728-6.5: Seat Front Edge Static Load test
|
2pcs: GT-LB01-9 BIFMA 102&50mm loading pad
2pcs: Armrest Durability loading pad
2pcs: Small seating loading pad
1pc: Tilt Mechanism test clamp
1set: Chair clamp
1pc: Large seating loading pad
2pcs: Local seating loading pad
1pc: Armrest vertical static clamp
2pcs: BIFMA 203mm loading pad
1set: Chair holder
|
|
EN1728-6.6：Vertical load on back rests
|
|
|
EN1728-6.8：Foot rest static load test
|
|
|
EN1728-6.10：Arm rest sideways static load test
|
|
|
EN1728-6.11：Arm rest downwards static load test
|
|
|
EN1728-6.13：Vertical upwards static load on arm rests
|
|
|
EN1728-6.14：Vertical static load on auxiliary writing surfaces
|
|
|
EN1728-6.18 Seat front edge durability test
|
|
|
EN1728-6.20：Arm rest durability test
|
|
|
EN1728-6.21：Foot rest durability test
|
|
|
EN1728-6.22：Auxiliary writing surfaces durability test
|
|
|
EN1728-7.4Seat front edge static load test
|
|
|
EN1728-7.5：Arm rest downward static load test – central
|
|
|
EN1728-7.6：Arm rest downward static load test – front
|
|
|
EN1728-7.7：Arm rest sideways static load test
|
|
|
EN1728-7.8：Foot rest static load test
|
|
|
EN1728-7.10：Arm rest durability
|
|
|
BIFMAX5.1Section5：Backrest Strength Test - Static - Type l
|
|
|
BIFMAX5.1Section6：Backrest Strength Test - Static - Type II & lll
|
|
|
BIFMAX5.1Section9：Tilt Mechanism Test - Cyclic
|
|
|
BIFMAX5.1Section10.4：Seating Front Corner Load-Ease Test
|
|
|
BIFMAX5.1Section12：Arm Strength Test - Vertical - Static
|
|
|
BIFMAX5.1Section13：Arm Strength Test - Horizontal - Static
|
|
|
BIFMAX5.1Section14：Backrest Durability Test - Cyclic - Type l
|
|
|
BIFMAX5.1Section15：Backrest Durability Test - Cyclic - Type Il and lll
|
|
|
BIFMAX5.1Section17: Leg Strength Test - Front and Side Application
|
|
|
BIFMAX5.1Section18：Footrest Static Load Test - Vertical
|
|
|
BIFMAX5.1Section19：Footrest Durability Test - Vertical - Cyclic
|
|
|
BIFMAX5.1Section20：Arm Durability Test - Cyclic
|
|
|
BIFMAX5.1Section22：Tablet Arm Chair Static Load Test
|
|
|
BIFMAX5.1Section23：Tablet Arm Chair Load Ease Test - Cyclic
|
|
|
BIFMAX5.1Section24：Structural Durability Test -Cyclic
|
|
|
3. ( Chair Swivel test)
|
EN1728-6.29 ：Castor and chair base durability (method1)
|
1set: 240LB~270LB Cumulative type Weight
1set: Chair holder
|
|
EN1728-7.11：Swivel test
|
|
|
EN1728-7.13 Castor and chair base durability (method1)
|
|
|
BIFMAX5.1Section 8：Swivel Test - Cyclic
|
|
|
4.(Castor Rolling resistance and durability tester)
|
EN1728-6.29：Castor and chair base durability (method2)
|
1set: 240LB~270LB Cumulative type Weight
1set: stop
|
|
EN1728-6.30Rolling resistance of the unloaded chair
|
|
|
EN1728-7.13 Castor and chair base durability (method2)
|
|
|
EN1728-7.14Rolling resistance of the unloaded chair
|
|
|
BIFMAX5.1Section16：Caster/Chair Base Durability Test - Cyclic
|
|
|
5.( Front Stability)
|
BIFMAX5.1Section11.4Front Stability
|
1set: 600N weight
1pc: seating loading pad
|
|
6.( Out Stop Tests and Back& Arm impact test)
|
EN1728-6.25Back impact test
|
1pc: 25KG: Impact weight
1set: 74kg Loading weight
1set: GT-LB01-7 Impact hammer
1set: Chair holder
|
|
EN1728-6.26Arm rest impact test
|
|
|
BIFMAX5.1Section21：Out Stop Tests for Chairs with Manually Adjustable Seat Depth
|
|
|
7.( Stability Tester)
|
EN1022 section 6
|
5pcs: 100N weight
2pcs: 50N weight
|
|
8.( Drop tests)
|
EN1728-6.27 Drop tests
|
1ps: Wedge device (adjustable angle)
1set: Stops
|
