Mouth-Actuated Tester GT-M03

(Toys Testing)

Item NO.:
GT-M03
Lead Time:
20-30 days
Brand:
GESTER
Payment:
T/T, L/C
certificate:
ISO 9001, UKAS, CE
standard:
EN 71-1, ISO 8124-1, ASTM F963, GB 6675.2

Download Contact Now

Description

Mouth Toy Durability Tester

Applications:

Mouth-actuated Toy Durability Tester is suitable for the test of the safety of the Mouth-Actuated Toys, such as whistles with a ball, the sounders with a reed and other toys.

Mouth Actuated Toys Tester will blow-off certain volume gas in a certain speed and inhale the toy, blow-off and inhale alternately for 10 times, after the test, you should test the toy and the deciduous parts whether they are findings.

Standards:

EN-71-1 section 8.17.2; ISO 8124-1 section 5.20

ASTM F963 section 8.13; GB 6675.2 section 5.20

Key Specifications

Model	GT-M03
Blow and suck air volume	295±10 cm³
Blow and suck frequency	1 cycle/ 5s
Test air pressure	13.8 Kpa
Testing times	10 times
Air pressure meter	Digital, Units, Kpa; The positive and negative pressure display
Dimensions (L×W×H)	27×56×39cm
Weight	≈24kg
Power supplier	AC220V 50/60HZ
Accessories	Tube gripper -3pcs

The Safety Requirement Of Mouth Toy Durability Tester

a): Mouth-actuated toys Durability Tester and removable mouthpieces of mouth-actuated toys shall not be the small objects. (shall not fit entirely in the small parts cylinder.)
b): Non-detachable mouthpieces of mouth-actuated toys, if detached when in accordance with immersion test, torque test and tension test, shall not release small objects. (shall not fit entirely in the small parts cylinder.)
c): Mouth-actuated toys Durability Tester which contain loose components, when tested in accordance with durability of mouth-actuated toys, should not release any small objects. (Subject the toy to 10 alternating blowing and sucking cycles, each within 5s and of at least (295±10cm3 of air)
d): Removable or non-detachable mouthpieces fitted to balloons shall conform to the requirements in a) and b).

Mouth Actuated Toys Tester

Applications Industry

All kinds of children products can be tested on the Mouth-actuated tester.

Mouth Toy Durability Tester
